Brewhouses

Our brewhouses are designed to streamline the brewing process, ensuring efficiency and quality at every stage. The process begins with mashing, where a mix of grain and water is heated in a mash tun. The mixture is then transferred to a lauter tun to obtain clear wort. This clear wort is pumped into a boil kettle, where it is boiled for approximately 60 minutes and hops are added. Finally, the wort undergoes whirlpooling, which forces denser solids into a cone at the center of the whirlpool tank, ensuring a clean and high-quality brew. Our brewhouses are engineered to deliver consistent results, making them ideal for both craft and large-scale breweries.

Capacity: 1000L, customizable
Material: SUS304 or SUS316

Specification Detai Features

Specification

Specification of Brewhouses

Item No.	ZJ-1000BH01
Product name	Brewhouse
Capacity	1000L, customizable
Material	SUS304 or SUS316
Heating way	Steam heating
Voltage	200v, 208V, 220V, 240V, 380V, 400V, 415V (customizable)
Control	Manual control
Thickness	Inner tank: 3mm, outer shell: 2mm, insulation: 80mm
Application	brewing process

Detai

Detail of Brewhouses

01

The 2 vessel brewhouse consists of two vessels. There are four processes in beer brewing, mashing, lauter, kettle, and whirlpool. Because there are only two containers, each container needs to complete two processes. Under normal circumstances, the saccharification and filtration processes completed in one tank. The boiling and spin-sinking process completed in another tank. It is composed of mash/ lauter tun, brew kettle/whirlpool.
02
- Capacity: 10HL/Batch
- Material: SUS304 or SUS316
- Application: Restaurants, bars, hotels, brewery
- Heating way: Steam heating, Electric heating
- Min/Max Plato Range: 12-16
- Inner Surface Treatment: Acid washing and passivating the Interior finish to 0.2-0.3um, 80mm rock wool for insulation
- Jacket Pressure: Design pressure: 0.3 MPa, Working pressure (steam heating): <0.2 MPa
- Cleaning: Top 360° self-rotating spray ball and CIP tube
- Degree of Automation: Semi-automatic, Fully automatic

Features

Features of Brewhouses

All pumps and motors with VFD control, guarantee the most reasonable liquid transfer.

Pump with water cooling to extend the equipment’s life.

More professional jackets and steal line design, to improve efficiency.

More reasonable piping line design, making the operation much easier and more efficient.

The overall design achieves the maximum energy saving.

Higher-level automation guarantees a good production record.
